Potato Digger Formedium size Tractors - DELEKS®- Pto Shaft included - Can be used for a range of different crops.
The DPT Potato Digger has been designed to be used on medium size tractors. The machine is made up of a vibrating digging plowshare with adjustable digging depth that conveys the potatoes and the earth onto a vibrating sieve grid that separates the potatoes from the earth, thus depositing them on a single cut row. It fits most common tractor brands: New Holland TK4000, T3030, T3F, John Deere serie 3-4, Landini Mistral, Antonio Carraro Tigrone, Kubota L, Deutz-Fahr, Lamborghini EGO 45-55, McCormick, Same Solaris, etc. Universal 3 point linkage Cat.1. EC Declaration of Conformity.
BENEFITS & FEATURES
Full plots of potatoes can be dug up in one go.
Can be used for a range of different crops.
Can be used on flat plain or on terrain with a range of different gradients.
Rubber silent block reduces vibration during use to give the machine longevity.
Simple effective design.
Pto Shaft included.
Documentation supplied with this article:
Invoice or Receipt
EC Certification and Risk Analysis (Valid throughout Europe) edited by ECO Spa (Faenza - Italy).
|Caracteristic||Units metric||Units US|
|Overall width||1500.0 mm||4.92 ft|
|Weight||272.0 kg||600.0 lb|
|Overall height||1100.0 mm||3.60 ft|
|Tractor Power Range||35 - 60 Hp||35 - 60 Hp|
|3 point linkage||Cat. 1-2 (ø 19.0-22.0mm / 25.0-28.0mm)||Cat. 1-2 (ø 19.0-22.0mm / 25.0-28.0mm)|
|Position of the gearbox||400.0 mm from left side / 700.0 mm from right side||15.75 in from left side / 27.56 in from right side|
|3 point linkage Thickness||12.0*60.0 mm||0.47 - 2.36 in|
|Spacing between the 2 lower points||555.0 - 820.0 mm||21.85 - 32.28 in|
|Overall length||1600.0 mm||5.25 ft|
|Distance between the 2 lower points and ground||580.0 mm||22.83 in|
|Diameter of the wheels||380*9.0 mm||15.0*0.35 in|
|Effective Working width||630.0 mm||2.07 ft|
|Distance between pto attachment and base||680.0 mm||26.77 in|
|Pto shaft||CE 6x800 mm + clutch ø180mm||CE 6x800 mm + clutch ø180mm|
|Rotation of gearbox||Right side||Right side|
|PTO||540 r/min||540 r/min|
|Packing sizes||1150.0*1600.0*100.0 mm||3.77*5.25*3.28 ft|
