DETAILS
Adjustable potato lifter for two-wheel tractors, 12 kg (26 lb): it lifts the potatoes and leaves them on the surface without cutting them, width adjustable to the row. It bolts straight onto the rear flange of the DELEKS® ZEUS two-wheel tractor with two bolts, in place of the female quick hitch: no drive and no 3-tooth hitch; it works with the handlebars in the rear position, using the weight and traction of the machine. Free delivery within the EU; if it is not compatible with your two-wheel tractor, returning it is free.
Trailed work, no drive
No moving parts: the implement bites into the ground with the weight of the tractor and the grip of the wheels, with the differential lock engaged in hard ground and steel wheels or ballast weights when rubber wheels spin. On the flat and in worked ground the 9 hp diesel is enough; the 14 hp petrol has more in reserve.
Two-bolt flange mounting
No quick hitch needed: undo the two bolts of the female quick hitch on the tractor and fit the implement's plate in its place, 125 × 78 mm (4.9 × 3.1 in), with a Ø 40 mm (1.57 in) centring hole and two Ø 12.5 mm (0.49 in) holes at 100 mm (3.94 in) centres. To go back to driven attachments, refit the female hitch. For BCS, Ferrari, Pasquali and other makes, ask the DELEKS® team and give the model: if it does not fit, returning it is free.
Fields of application
- Vegetable plots and smallholdings: light ploughing, furrows, earthing up
- Potatoes and row crops: ridging at planting, lifting at harvest
- Weeding between the rows with the cultivator
- Worked or light ground, where a rotary plough is not needed
FAQ
Do I need anything else to fit it?
No: it bolts to the tractor's flange with two bolts, in place of the female quick hitch, which goes back on when you return to driven attachments.
Will it fit my BCS, Ferrari or Pasquali?
It depends on your tractor's flange: ask the DELEKS® team and give make and model. If it does not fit, returning it is free.
DELEKS® spare parts and service
Genuine spare parts ship from the DELEKS® warehouses in Europe: tines, blades, knives, belts, filters, control cables and the other wearing parts are normally in stock, for routine and for unscheduled maintenance. The technical service helps you find the right part from the exploded drawings, service the machine and choose the attachments that suit your work. The product comes with the EC declaration of conformity, the invoice and the use and maintenance manual, also emailed when the order ships. Two-year warranty, free delivery within the EU and free returns on attachments that do not fit your two-wheel tractor.
CHARACTERISTICS
| Characteristic | Units metric | Units US |
|---|---|---|
| Weight | 12.0 kg | 26.0 lb |
| Gross shipping weight | 20 kg | 44 lb |
| Package volume | 0.14 m3 | 4.9 cu ft |
