Hay forks for tractors D-700-K

Available
CodeD700K
EAN 8053470230110
See more details

2 YEARS WARANTY

30 DAYS FOR RETURN

5-10 DAYS OF SHIPPING

SECURE PAYMENT


DETAILS

Hay bale forks DELEKS® for tractors like New Holland, John Deere - Load capacity 700kg.



OVERVIEW

Designed for hay bales, both round and square as well as other baled material.

Designed to fit most medium size tractors e.g New Holland T3030, T4F, John Deere 4-5 Series, Landini Mistral, Lamborghini Ego 45-55, McCormick, Kubota L, Same Solaris, CASE, Deutz-Fahr, etc. EC Conformity, 2 Year warranty.



BENEFITS & FEATURES

Deleks carriage design allows fork tines to be easily re-spaced or changed and locked into place.

Rigid, high-strength steel frame built to last.

Loading capacity of 700kg.

The weight of the load is distributed over three points so it will not cause stress failures.

Conical tapered tines are less likely to cling to baled material.

Forks can be folded away during transit when not in use.



CARACTERISTICS

Caracteristic Units metric Units US
Overall width 950.0 mm 3.12 ft
Weight 77.0 kg 170.0 lb
Overall height 980.0 mm (open) 38.60 in (open)
Tractor Power Range 20 - 90 Hp 20 - 90 Hp
3 point linkage Cat. 1-2 (ø 19.0-22.0mm / 25.0-28.0mm) Cat. 1-2 (ø 19.0-22.0mm / 25.0-28.0mm)
Load capacity 700.0 kg 1544.0 lb
3 point linkage Thickness 10.0 mm 0.40 in
Spacing between the 2 lower points 580.0 / 840.0 mm 22.84 / 33.0 in
Usable Fork Tine Length 1165.0 mm 45.87 in
Fork Tine Length 1203.0 mm 47.36 in
Fork Tine Weight 9.2 kg 20.28 lb
Fork Tine Spacing (min-max) 198.0 / 673.0 mm 7.80 / 26.50 in
Positions of the forks 3 + 3 3 + 3
Diameter of the horizontal tube 40.0 mm 1.58 in
Distance between the 2 lower points and ground 185.0 / 285.0 / 385.0 mm 7.28 / 11.22 / 15.15 in
Overall Length (open and closed) 1240.0 / 280.0 mm 48.80 / 11.00 in
Fork Tine Diameter 42.0 mm 1.65 in
Packing sizes 1200.0*950.0*300.0 mm 47.25*37.40*11.80 in
